Follow the Flow

The heart has 4 valves and 4 chambers. The valves are one-way “doors” that keep blood moving forward and prevent backflow.

To understand how blood moves through the heart, we can number the valves in the order in which the blood passes through them as it travels from the venous to the pulmonary and then to the arterial side.

The Sequential Order of Heart Valves

1. Tricuspid Valve: The first valve. It allows deoxygenated blood to flow from the Right Atrium into the Right Ventricle. Tri=3 leaflets for the valve

2. Pulmonary Valve: The second valve in the sequence. It opens to allow blood to be pumped from the Right Ventricle into the Pulmonary Artery on its way to the lungs. There are 3 leaflets for the pulmonary valve.

3. Mitral Valve (also called the Bicuspid Valve): After the blood is oxygenated in the lungs, it returns to the Left Atrium and passes through this third valve into the Left Ventricle. Bi (cuspid) = 2 leaflets for the valve.

4. Aortic Valve: The final valve. It opens to allow oxygen-rich blood to leave the Left Ventricle and enter the Aorta, which distributes it to the rest of the body. 3 leaflets for the aortic valve.

Two Quick Memory Tricks

Here are a few solid memory tricks to help you remember the right-to-left valve sequence

(Tricuspid → Pulmonary → Mitral → Aortic):

“Toilet Paper My Ass” = Tricuspid, Pulmonary, Mitral, Aortic

Cleaner option: “Try Pulling My Aorta” = Tricuspid, Pulmonary, Mitral, Aortic

Bonus Valve Information

The Rule of Three

3 valves have 3 leaflets:

• Tricuspid

• Pulmonary

• Aortic

This design allows a wide opening for flow and tight closure under pressure.

The Mitral Exception

The Mitral valve has 2 leaflets.

It sits on the left side of the heart and handles the highest pressures (transvalvular).

It is supported by chordae tendineae and papillary muscles, which prevent it from prolapsing back into the left atrium.

Why This Matters at the Bedside

If you understand the sequence, you can troubleshoot faster.

Example:

• Pulmonary edema? Think Mitral or left side problem

• High CVP and congestion? Think Tricuspid or right side problem

• No pulse pressure on VA ECMO? Think Aortic valve not opening

Start with flow. Then find where it’s blocked or leaking.
